Length: | 94.9 in |
Overall width: | 38.4 in |
Overall height: | 53.1 in |
Seat height, laden: | 26.7 in |
Seat height, unladen: | 28.0 in |
Ground clearance: | 5.5 in |
Rake (steering head): | 26 |
Trail: | 6.7 in |
Wheelbase: | 64.0 in |
Tires, front specifications: | 130/60B19 M/C 61H |
Tires, rear specifications: | 180/55B18 M/C 80H |
Fuel Capacity: | 6.0 gal |
Oil capacity: | 5 qt. |
Weight, as shipped: | 800 lbs |
Luggage capacity – volume: | 2.2 cu ft (0.062 m3) |
Tire, type: | Dunlop® Harley-Davidson Series, bias blackwall front and rear |
Fork angle: | 30 |
Reserve fuel capacity, fuel injection: | 1.0 gal |
Engine: | Milwaukee-Eight® VVT 121 |
Bore: | 4.1 in |
Stroke: | 4.6 in |
Displacement: | 120.64 in3 |
Compression ratio: | 11.4:1 |
Fuel system: | Electronic Sequential Port Fuel Injection (ESPFI) |
Air cleaner: | Synthetic Felt, Washable |
Exhaust: | 2-1-2 dual exhaust |
Lubrication system: | Pressurized, dry-sump |
Engine torque testing method: | J1349 |
Engine torque: | 139.4 ft-lb |
Engine torque (RPM): | 3,000 |
Horsepower: | 115 HP / 86 kW @ 4500 rpm |
Lean angle, right (deg.): | 32 |
Lean angle, left (deg.): | 32 |
Fuel economy testing method: | Estimated City/Hwy |
Fuel economy: | 45 mpg (5.1 l/100 km) |
Primary drive: | Chain, 34/46 ratio |
Gear ratios (overall) 1st: | 9.593 |
Gear ratios (overall) 2nd: | 6.65 |
Gear ratios (overall) 3rd: | 4.938 |
Gear ratios (overall) 4th: | 4 |
Gear ratios (overall) 5th: | 3.407 |
Gear Ratios (overall) 6th: | 2.875 |
Final drive: | Belt, 32/68 ratio |
Clutch: | Mechanically actuated 10 plate, wet Assist & Slip |
Transmission: | 6-Speed Cruise Drive® |
Front fork: | 47 mm Inverted 1x1 Front Forks |
Rear shocks: | Dual adjustable emulsions suspension with remote preload adjustment on the left shock, and threaded preload on the right shock |
Wheels, front type: | Combo Cast Laced |
Wheels, rear type: | Combo Cast Laced |
Brakes, type: | Dual floating rotors (front), fixed rotor (rear) |
Brakes, caliper type: | 32 mm, 4-piston fixed dual radially mounted front, and single axially mounted rear |
Frame: | Mild steel; tubular frame, two-piece stamped and welded backbone; cast and forged junctions; twin down tubes; bolt-on rear frame with forged fender supports; MIG welded |
Swingarm: | Mild steel, two piece drawn and welded section; forged junctions; MIG welded |
Lights (as per country regulation), Headlamp: | LED |
Lights (as per country regulation), Tail/Stop: | LED |
Lights, front signal lights: | LED |
Lights, rear turn signals: | LED |
Gauges: | Digital gauges integrated within the display |
Battery: | Sealed, maintenance-free, 12V, 28-amp/hour, 405 cca (per Battery Council International Rating) |
Charging: | Three-phase, 58-amp system (754W max power @ 13V) |
Starting: | 1.6 kW electric with solenoid shift starter motor engagement |
Electric power outlet: | 15 Watt USB-C electric power accessory port in media storage box. |
GPS System: | Yes, imbedded navigation system with real-time traffic and weather via Wi-Fi Hotspot |
Screen size: | 12.3 in (312 mm) |
Infotainment system: | Skyline™ OS |
Type: | Full Color TFT |
Watts per channel: | 125 |
Speakers: | 4 |
Speaker size: | Two 6.5in fairing speakers, and two 5x7in saddlebag speakers |
Headset specifications (if equipped): | Harley-Davidson Packtalk Edge wireless Bluetooth® headset |
AM: | Standard |
FM: | Standard |
Weather Band (WB): | Supported |
Languages: | Arabic, Bahasa (Indonesian), Catalan, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (UK/USA default), Finnish, French (Canada/France), German, Hebrew, Hungarian, Indonesian, Italian, Japanese, Korean, Malay, Norwegian, Polish, Portuguese |
Hands-free mobile phone — via Bluetooth: | Standard |
Voice recognition: phone functions only: | Phone dependent |
Voice Recognition Languages: Tuner / Media / Navigation: | Phone dependent |
Text-to-Speech (TTS) languages: | Phone dependent |
Rider / passenger intercom: | Standard (passenger headset sold separately), VOX is available for HD headsets |
Vehicle information screen: | Standard |
USB: | USB-C/MTP/iPod/iPhone, any device with proper adapters to the electric power outlet located in the inner fairing storage. |
Bluetooth: | Phone/Media Player, Headset |
